Sammelschienenklemme MERSEN

MULTIFIX 60 is a system for power distribution on copper bars with 60mm busbar spacing, which consists of a variety of modularly combinable components. The system can be loaded up to 630 A, 400 VAC, 500 VAC, 690 VAC, 45–62 Hz. The short-circuit strength is tested according to VDE 0660 part 500 and IEC 60439-1. MULTIFIX 60 can be used in 3, 4 and 5-pole versions. The drilling-free assembly of the components of the MULTIFIX 60 system offers great flexibility for extensions and changes to existing installations and systems and guarantees a short assembly time. The MULTIFIX 60 D0 bus-mounting fuse bases are among the most user-friendly devices currently on the market. A label integrated directly on the base prevents mix-ups during maintenance and assembly work. The use of stainless steel terminals for feeding up to 25mm² allows easy wiring and ensures low power loss. The busbar support can be built over with covers that are widened on the left and right. The audible click on the busbars guarantees that the device is securely in place. In addition to the touch protection on the front with 27mm, 36mm and 54mm covers, reaching behind and busbar protection is also possible with modular covers that can be attached at the top.
